Osculati AISI 316 Rectangular Weld-On Pulpit Socket – Ø22/25 mm, 90°/60°
The Osculati rectangular pulpit socket is manufactured from precision-cast mirror-polished AISI 316 stainless steel and is designed to be welded into pulpit rail installations. The construction is specified as very sturdy, with a fine design, and better than moulded plate models.
All versions feature a rectangular base measuring 76.2 × 44 mm. The range includes models for Ø22 mm and Ø25 mm pipe, available with either a 90° or 60° slope.
Key Features
- Made from precision-cast AISI 316 stainless steel
- Mirror-polished finish
- Designed to be welded
- Rectangular base
- Base dimensions: 76.2 × 44 mm
- Available for Ø22 mm and Ø25 mm pipe
- Available with 90° or 60° slope
- Very sturdy construction
- Fine design
- Better than moulded plate models
Available Versions
| Code | Version | Base Size | Slope | For Pipe Ø |
|---|---|---|---|---|
| 41.260.22 | Rectangular | 76.2 × 44 mm | 90° | Ø22 mm |
| 41.261.25 | Rectangular | 76.2 × 44 mm | 90° | Ø25 mm |
| 41.258.22 | Rectangular | 76.2 × 44 mm | 60° | Ø22 mm |
| 41.259.25 | Rectangular | 76.2 × 44 mm | 60° | Ø25 mm |
Technical Specifications
| Material | AISI 316 stainless steel |
|---|---|
| Construction | Precision-cast |
| Finish | Mirror-polished |
| Installation | Weld-on |
| Base Type | Rectangular |
| Base Size | 76.2 × 44 mm |
| Pipe Diameter Options | Ø22 mm / Ø25 mm |
| Available Slopes | 90° / 60° |
