Plastimo Aluminium Disc Anodes – Ø110 / Ø150 mm
The Plastimo aluminium disc anodes are sacrificial anodes designed for marine corrosion protection. The range includes three aluminium variants with outside diameters of 110 and 150 mm and different heights.
Plastimo 53052 has an outside diameter of 110 mm and a height of 25 mm. Plastimo 177386 also has an outside diameter of 110 mm but a height of 31 mm, with internal diameters of 36 mm and 14.5 mm and a weight of 0.390 kg. Plastimo 53053 is the larger Ø150 mm version with a height of 29 mm.
Available Models
| Plastimo Code | Material | Dimensions | Additional Dimensions | Weight |
|---|---|---|---|---|
| 53052 | Aluminium | Ø110×25 mm | – | – |
| 177386 | Aluminium | Ø110×31 mm | Ø1 36 mm / Ø2 14.5 mm | 0.390 kg |
| 53053 | Aluminium | Ø150×29 mm | – | – |
Key Features
- Brand: Plastimo
- Material: Aluminium
- Type: Disc anode
- Outside Diameters: Ø110 and Ø150 mm
- Available Heights: 25, 29 and 31 mm
- Supply: Pair with screw
Select the appropriate version according to the required outside diameter, height and mounting dimensions.
