The Quick GP2 500 horizontal on-deck windlass is suitable for boats from 6-8 meters (20 -26 ft) and is supplied with a 12V T6411-12 contactor unit and a lever for the windlass as standard.
This particular model has a white composite material base and features an 8mm gypsy which is suitable for 8mm DIN 766, 8mm ISO and 5/16″ G4 chain, as well as 1/2″ (12.7mm) rope. (PLEASE NOTE these values refer to a three-strand polyester rope with a rope/chain splice manufactured with the Quick system).
Product contents include the windlass (on deck unit and motor gearbox), contactor unit, base gasket, drill template, handle, bolts and screws (for assembly), user’s manual and conditions of warranty.
Drilling Template GP2 500
Technical Manual GP2 Genius 500 1200 D F
