Features:
- Brass and copper elements for maximum range and efficiency
- Stainless steel ferrule with standard 1-14 thread
- 20ft RG-8/X low-loss cable plus a PL-259 connector
Specifications:
- 2 Sections: Base 75 Tip 39
- Band:VHF Marine Band
- Antenna Gain:6dB
- Max. Input Power:100 watts
- SWR:nominally 1.5:1 at 156.8 MHz
- Bandwidth:3 MHz within 2.0:1 VSWR
- Ferrule:Stainless steel
- Coax Supplied:20 ft of RG-8/X
- Connector Supplied:PL-259, not installed
- Color/finish:Galaxy White
- Polarity:Vertical
- Impedance:50 Ohms
- DC Ground:DC Grounded – The antenna will read shorted on continuity test.
