Maxwell AA560 Panel Mount Rode Counter and Windlass Control (Vetus P102944)
| Specification | Details |
|---|---|
| Article Number | Vetus P102944 |
| Product Type | Panel-mounted rode counter with integrated windlass control |
| Mounting Type | Panel mount console |
| System Type | Wired control unit |
| Power Supply Compatibility | DC, AC, and hydraulic windlasses |
| Display | Graphic backlit LCD |
| Display Units | Metres, feet, or fathoms (selectable) |
| Rode Type | All-chain or rope/chain |
| Docking Alarm | Audible alarm during final anchor retrieval |
| Preset Functions | Preset stopping point and one-touch deploy/retrieve of preset rode length |
| Windlass Data Display | Windlass speed and direction |
| Operating Hours Log | Yes |
| Safety Lock | Integrated safety lock to prevent accidental activation |
| Number of Consoles Supported | Up to three consoles per vessel |
| Sensor Gap Range | 3–50 mm |
| Environmental Protection | IP67 (front, when correctly installed) |
| Compliance | EMC protected to CE EN60945 |
Functional Features
- Real-time display of deployed chain or rope/chain length
- Preset stopping point for controlled and safe anchor retrieval
- One-touch automatic deployment and retrieval of preset rode lengths
- Audible docking alarm warns when anchor approaches fully docked position
- Graphic LCD interface with intuitive menu navigation
- Displays windlass speed and direction during operation
- Integrated safety lock to reduce risk of accidental windlass operation
- Logs windlass operating hours to support scheduled maintenance
System Compatibility
- Suitable for DC, AC, and hydraulic windlass systems
- Compatible with most vertical windlasses
- Some horizontal windlasses may require an optional sensor holder
- Designed for multi-station installations with up to three AA560 consoles
- Requires installation with a dual-direction control box or solenoid pack
Kit Contents
- Panel-mounted console unit (with weather cover)
- Grey sensor
- Magnet(s)
- Load sensing connectors
- Installation and operation manual
Not Included
- Sensor cable (available separately in various lengths)
- Optional sensor holder for certain horizontal windlasses
Important Notes
- The AA560 provides both rode counting and windlass control functions
- Installation should be carried out by a qualified marine electrician
- Three-year warranty for leisure use; one year for commercial or charter applications
